High-Performance Stainless Steel Storage Tanks: Secure & Hygienic Containment

In industrial processing, the integrity of your raw materials and finished products depends on the quality of your storage solutions. Our Stainless Steel Storage Tanks are engineered to provide maximum durability, corrosion resistance, and structural stability. Whether you are storing high-purity water, volatile chemicals, or viscous food ingredients, these tanks ensure zero contamination and long-term reliability.

We offer three specialized tiers—Basic, Advance, and Pro—tailored to meet the specific demands of your facility, from general industrial storage to high-end aseptic pharmaceutical requirements.

---

Technical Specifications & Comparison

Our SS Storage Tanks are fabricated using premium-grade alloys and advanced TIG welding with argon purging to ensure smooth, leak-proof seams.

Feature Comparison Table

Feature	Basic Model	Advance Model	Pro Model
Material Grade	SS 304	SS 316	SS 316L (Low Carbon)
Tank Geometry	Vertical / Horizontal	Vertical with Dish End	Custom Sloped / Conical
Surface Finish	Industrial Matte	Mirror Polish (240 Grit)	Electropolished (Ra < 0.2 µm)
Shell Thickness	2mm – 5mm	3mm – 10mm	Custom High-Pressure
Sealing Gasket	Food-Grade Silicone	EPDM / Viton	High-Purity Teflon (PTFE)
Inlet/Outlet	Threaded / Flanged	Flanged / SMS Union	Tri-Clover (TC) Sanitary
Level Monitoring	Visual Sight Glass	Digital Level Indicator	Ultrasonic / Load Cells

---

Detailed Model Breakdown

1. Basic Model: Durable Utility

The Basic Model is a cost-effective solution for general-purpose water storage, non-corrosive liquid handling, and atmospheric pressure applications.

• Standard SS 304 Build: Offers excellent resistance to oxidation and is suitable for treated water, oils, and mild detergents.

• Open or Closed Top: Available with a removable bolted lid for easy access during manual cleaning or bulk loading.

• Fixed Support: Mounted on robust stainless steel legs with base plates for easy floor mounting.

2. Advance Model: The Industrial Standard

The Advance Model is designed for the food, beverage, and chemical industries where product purity and easy maintenance are essential.

• SS 316 Metallurgy: Enhanced with Molybdenum to provide superior resistance to chlorides and acidic environments, preventing pitting and corrosion.

• Sanitary Internal Finish: Internal welds are ground smooth and mirror-polished to prevent bacterial growth and ensure easy washdowns.

• Integrated Venting: Features a high-quality air vent filter to prevent vacuum formation or overpressure during filling and draining cycles.

3. Pro Model: Ultra-High Purity & Aseptic

Our Pro Model is the definitive choice for the Pharmaceutical and Biotech sectors (Aseptic Grade), where zero-contamination is mandatory for regulatory compliance.

• SS 316L & Electropolishing: The use of low-carbon steel combined with electropolishing results in a microscopic smoothness that resists microbial adhesion and facilitates validated CIP (Clean-in-Place).

• Aseptic Design: Features “dead-leg-free” nozzle designs and a sterile-grade 0.2-micron hydrophobic vent filter for atmospheric protection.

• Precision Monitoring: Can be fitted with load cells for high-accuracy weighing and automated level sensors that interface directly with your facility’s PLC/SCADA system.

• Full Documentation: Supplied with a comprehensive validation pack, including material test reports, surface roughness certificates, and hydro-test reports.

---

Key Features of Our Storage Solutions

• Precision Welding: We utilize specialized welding techniques to ensure every seam is as strong as the parent metal, providing a service life of 20+ years.

• Zero Contamination: Our post-fabrication pickling and passivation process removes all surface impurities, ensuring the tank remains chemically passive.

• Customizable Fittings: All models can be customized with spray balls for CIP, thermowells for temperature monitoring, and sampling valves for quality control.

• Ergonomic Design: Includes features like non-slip ladders, safety railings, and side-entry manways for safe and easy operator access.

---

Wide Range of Applications

• Pharmaceuticals: WFI (Water for Injection) storage, purified water tanks, and buffer holding.

• Food & Dairy: Milk silos, juice storage, syrup blending, and edible oil containment.

• Cosmetics: Perfume aging tanks, bulk cream storage, and lotion holding.

• Chemicals: Solvent storage, intermediate chemical tanks, and hazardous liquid containment.
